Manual Control Cast Iron Axial Piston Pumps For High Pressure Hydraulic Systems
Product Description:
We Highland are proud to offer top-level axial hydraulic pump and hydraulic motor assemblies with the highest quality and performance. Our charge pump is a variable displacement pump, and the motor assembly can be either quantified or variable, dependent on the application.
Available as manual or hydraulic control, our pumps and motors can easily regulate speed, direction and power of the output shaft. The medium pressure axial piston pump has the capacity for a pressure of up to 42Mpa, and is designed for closed circuit mobile applications. They are reliable, quiet and efficient.
Our hydraulic systems are designed for comfortable and reliable operation. Moreover, it follows the ergonomic concept for perfect performance in parameters.
Features:
- Maximizing Performance, Efficiency, and Profit with Axial Piston Pumps
- Axial piston pumps are the choice for hydraulic systems, as their maximized efficiency helps to lower total costs. The design of these pumps is deliberately compact, keeping the overall operation simple while preserving the highest quality. Moreover, being lightweight and compact boosts the cleanliness and flexibility of the machine.
- The axial piston pumps offer precise control and reliable quality and performance, coupled with wide displacements ranging from 30 to 130 cm² per round. All this with a more than satisfying 420 bar transient pressure capability.
Technical Parameters:
| LPV hydraulic pump and LMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 |
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed
(Full load condition) | r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 |
| Min continuous working speed | r/min | 500 |
| Pressure | Rated working pressure | Mpa | 35 |
| Max working pressure (transient) | Mpa | 42 |
| Continuous working pressure | Mpa | 30 |
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 |
| Torque | Continuous output torque
(Under continuous working pressure) | Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 |
| Temperature | Allowable shell temperature | ℃ | 80 |
| Max working temperature of oil tank | ℃ | 70 |
| Weight | LPV series hydraulic pump
hydraulic oil emptying | kg | 45 | 46 | 63 | 64 | 82 | 88 |
LMF series hydraulic motor
hydraulic oil emptying | kg | 30 | 30 | 36 | 36 | 36 | 38 |
Applications:
Axial piston pumps are commonly seen in hydraulic transmission systems, particularly in powerful systems, such as those of construction machines, agricultural equipments, coal mining, oil extraction, aerospace, and shipbuilding.
Moreover, due to their ability in adjusting the flow, such pumps are extremely useful when it comes to high pressure, large flow, and power related systems. This is why we can find them in planers, broaching machines, hydraulic machines, and other construction applications.
Support and Services:
Axial Piston Pumps Technical Support and Service
Our goal is to provide the highest level of technical support and services for our Axial Piston Pumps. Our engineers have extensive experience in working with pumps and can provide technical support and services for any kind of pump.
Our technical support and services include:
- Analyzing and troubleshooting existing pump systems
- Providing design and installation advice
- Offering troubleshooting and maintenance tips
- Providing advice on pump selection, sizing, and operation
- Providing technical assistance and recommendations on pump upgrades and repairs
- Our team of experienced technicians is here to help you with any technical questions or problems you may have. We are committed to providing the highest level of service and support for our Axial Piston Pumps.
FAQ:
Q&A of Axial Piston Pumps
Q1: What is the brand of Axial Piston Pumps?
A1: The brand of Axial Piston Pumps is HIGHLAND.
Q2: What is the model number of Axial Piston Pumps?
A2: The model number of Axial Piston Pumps is LPV110.
Q3: Where is the place of origin of Axial Piston Pumps?
A3: The place of origin of Axial Piston Pumps is CHINA DEZHOU.
Q4: What is the certification of Axial Piston Pumps?
A4: The certification of Axial Piston Pumps is PATENT CERTIFICATE.
Q5: What is the minimum order quantity of Axial Piston Pumps?
A5: The minimum order quantity of Axial Piston Pumps is 5 Sets.
